功能特點 FUNCTIONAL
|
标配标準單舌鎖芯，可選配多舌鎖芯 Standard lock body,Doublbe latch lock body useful. |
|
鋅合金材質鎖闆及把手，緊固耐用 Zine alloy panels and handles.staudy and durable. |
|
M1卡感應芯片 M1 RF card. |
|
密碼防盜窺視輸入功能 Password screen with anti-peeking password inputting function. |
|
備用機械鎖芯采用超C級電腦鎖芯 Spare mechanical key with computer blockcore. |
|
上(shàng)提打反鎖功能 Handle Lifed locking |
|
多用戶管理 Multi-management |
|
低電壓報警功能 Low voltage alarm funtion |
|
可選配遙控器開啓 Remote control is useful. |
技術參數 TECHNOLOGY
|
感應卡片技術 Card technology |
一(yī / yì ／yí)卡通Mifarel感應芯片 Mifare 1 RF card. |
|
用戶容量 User capacity |
密碼用戶數量100組，卡用戶數量800組 100 passwords, 800 cards. |
|
工作電壓 Working voltage |
DC6V直流電池 DC6V ,DC battery. |
|
工作溫度 Working temperature |
-20~ +70°C |
|
工作濕度 Working humidity |
40%~85% RH (無凝霜) |
|
感應卡工作頻率 Frequency |
13.56MHz |
|
感應卡類型 Card Model |
可選擇: 标準卡片式、扣鈕式、貼膜式。 Standard formula, Buttoning style, Thin Film style. |
|
功耗 Power Consumption |
靜态功耗≤20微安。動态功耗≤200毫安。 Static current:≤20 uA,Dynamic current :≤200 mA |
|
密碼長度 Password length |
6-10位 6-10 digits |
|
适用門類型及厚度 Door Thickness |
适用于(yú)木門，厚度40-120mm Door thickness for 40-120mm |
|
面闆尺寸 Panel size |
長:161.5 寬:70 厚:38.5 Length:161.5 Width:70 Thickness:38.5 |
